MULTILIFT Ultima Series

Tri-Axle and Four-Axle Hooklifts

Request a Quote

MULTILIFT Ultima Series Hooklifts

MULTILIFT Ultima Series Hooklifts

​Standing still is never an option, and that is why MULTILIFT has taken hooklift technology to the next level with the MULTILIFT Ultima series, a tri- and four-axle hooklift. It is engineered with radical innovations that give greater control, safety, and productivity for all loading jobs.

From HiVision™ camera-guided technology and advanced connectivity, to a unique integrated weighing system and intuitive touchscreen controls, Ultima represents a new era for load handling – and for your business.

View MULTILIFT Products

MULTILIFT Ultima Series Models


MULTILIFT ULTIMA 14S

30000 lbs Capacity, 3595-4100 lbs Ship Weight, 54”/61.75” Hook Height, 14’-20’ Body Lengths.



MULTILIFT ULTIMA 14S

MULTILIFT ULTIMA 16S

40000 lbs Capacity, 3835-4280 lbs Ship Weight, 54”/61.75” Hook Height, 15’-20’ Body Lengths.

MULTILIFT ULTIMA 16S

MULTILIFT ULTIMA 21S

50000 lbs Capacity, 5510-5620 lbs Ship Weight, 54”/61.75” Hook Height, 18’-22’ Body Lengths.

MULTILIFT ULTIMA 21S

MULTILIFT ULTIMA 26S

60000 lbs Capacity, 6065 lbs Ship Weight, 54”/61.75” Hook Height, 20’-22’ Body Lengths.



MULTILIFT ULTIMA 26S

MULTILIFT ULTIMA 30S

72000 lbs Capacity, 6330 lbs Ship Weight, 61.75” Hook Height, 20’-22’ Body Lengths.

MULTILIFT ULTIMA 30S

MULTILIFT Ultima Features


Electric Cab Controls

All MULTILIFT Ultima systems are outfitted with electric cab controls as a standard feature, not an upgrade.


High Tensile Steel Construction

All MULTILIFT Ultima systems are constructed using a high tensile steel, reducing the amount of steel required to get the job done without compromising the system's integrity.


Dual Pivot Design

All MULITILIFT systems incorporate a dual pivot design, for smooth loading/unloading and true dump capabilities.

Hook Safety Latch

All MULTILIFT Ultima hooklifts include a hook safety latch, securing the bale bar at all times.


Body Up Warning Light

All MULTILIFT systems include a body up warning light, which is functional whenever the truck is powered on.

Sensors & Wiring

All MULTILIFT Ultima hooklifts: Outfitted with sensors and wiring that carry an IP67 rating, submersible up to 3' underwater.


nDurance Paint Process

All MULTILIFT Ultima hooklifts: Protected by the nDurance Paint Process. The steel is properly prepared prior to starting the paint process. An advanced zinc primer is applied, which virtually bonds to the steel surface. And finally, the process completed it with a finish top-coat of black. Note, all components are primed and painted prior to assembly. All non-painted components receive a zinc/nickel coating for maximum corrosion resistance.


Smart Proportional PLC Controller

ULTIMA Series: A standard feature that records and reports system activity to the operator at all times. Protects against unsafe operations, while providing full range proportional control. Expandable, able to accept and control third-party equipment (work lights, tarp systems, etc...).


DOWNLOAD OUR BUYING GUIDE

Whether you know exactly what you're looking for, or you are looking for more information on our product lines, download our first time buyer's guide for more information.

DOWNLOAD BUYERS’ GUIDES

Industry Challenges


Safety

MULTILIFT container handling hooklifts are the safest in the industry. At the bare minimum, all systems include: in-cab operation, body up warning system, hook safety latch, maintenance support and mechanical body locks. Operate with complete peace-of-mind.


Efficiency

The right equipment can change the course of your business. With a MULTILIFT container handler on the back, you'll instantly increase daily productivity. Incorporating the best safety features, smooth and fast operation built on a solid core, a MULTILIFT will help you start and finish each job efficiently and on time. Loading and unloading capacities are maximized for a truck’s available payload as well as the working environment.


Downtime

MULTILIFT's renowned reliability combines with unequaled product support. Every MULTILIFT hooklift is backed by a nationwide dealer and service network to ensure your equipment stays dialed in and operational.


Training

Training and educating operators takes time, but the MULTILIFT's leading-edge technology allows customers to manage their resources in the best way, whether the operator is highly experienced or a new employee.


Reliability

MULTILIFT is the industry leader in reliability and backed by the industry's only 2-year all parts warranty. Superior engineering and cutting-edge technology ensure optimum longevity and service life of your equipment.


Revenue

Designed using a high-strength light-weight steel (up to 40% lighter), MULTILIFT container handler maximizes your legal payload and profits with every trip. Add operating speeds up to 60% faster than competitive brands, MULTILIFT gets you in and out of job sites in record time. More trips per day equal more coin in your pocket.


Industry Leading Warranties

Using premium quality steel and components, superior workmanship and the industry’only 2-year all parts warranty, MULTILIFT hooklifts and roll-off cable hoists are built to last. Because we build them with the utmost care, we’re able to back them with confidence. When reliability counts, look no further.

MULTILIFT - Warranty Statement Summary

MULTILIFT Warranty Brochure


View All Operator's Manuals

Click through to view all Operator's Manuals for our equipment.

Click Here

Buyer's Guide

MULTILIFT Buyer's Guide

Spec Sheets

MULTILIFT - Hooklift Pump _ Hydraulic Data

Ultima 14 _ 16 - Hooklift Tech Data

Ultima 21, 26 _ 30 - Hooklift Tech Data

Ultima 21S Commander - Hooklift Tech Data

MULTILIFT Product Spec Brochure

Brochures

MULTILIFT - Commander Brochure

MULTILIFT - Ultima Brochure

 View All Operator's Manuals

Click here to view all Operator's Manuals.
