ZEPRO Z3N

TAIL LIFTS

A lightweight cantilever lift with a lifting capacity of up to 750kg. Available in three frame widths to fit all 3.5 tonne RWD, FWD or 4WD trucks.
One of the lightest and most versatile lifts on the market offering maximum payload and optimum capacity.
The lift weight starts at 152kg without underrun protection. The standard version includes cables, frame mounts and control units but can also be configured to suit individual requirements.
Other features include:
- A wide range of mounting brackets for fast and easy installation.
- Double acting tilt cylinders that ensure fast loading and unloading regardless of weather or temperature.
- A slip-resistant platform as standard.
- Suspended underrun protection enabling better ground clearance in comparison to fixed underrun protection.
- A foldable platform, suitable for both flatbeds and dropsides to prevent drag, improve visibility and lowers Co2 emissions.

Standard & Optional features

Model specifications

Lifting Capacity (Kg)
Platform Types
Platform Length Max. (mm)
Platform Width Max. (mm)
Lift Height Range (mm)
ZEPRO Z3N 75-100
750
Alu
1600
2400
1000
