Specification Renault - HIAB X-HiPro 558
- Hiab Corporate
- Installations
- FrameWorks and Bodyworks
- Specification Renault
Crane: HIAB X-HiPro 558 EP-5
Lifting capacity (ADC): 55,0 tm
Slewing angle: Continuous
Maximum outreach: 14,5 m
Type stabilisers: Tiltable
Stabiliser spread: 8000 mm
Oil flow: 120 liter/min
Installation space: 1283 mm
Type VSL: VSL and VSL+
Truck brand and type: Renault C480 6x2 rigid
Cabin: Sleeper cab
Cabin Color: Black
Wheelbase: 4900 mm
Tires front axle: 385 / 65 R22,5
Tires drive axle: 315 / 80 R22,5
Tires rear steer axle: 385 / 65 R22,5
Front axle capacity: 9 ton
Rear axle capactity: 19 ton (11,5 + 7,5)
Gross vehicle weight: 26 ton
Installation: Hiab FrameWorks
Type subframe: Hiab FrameWorks 5XX range high built
Type oil tank: Cyclone oil tank 135 Liter
Type pump: Load sensing variable
Type auxiliary stabiliser beam: HIAB 6m
